Scientists Design Molecular System for Artificial Photosynthesis

System is designed to mimic key functions of the photosynthetic center in green plants to convert solar energy into chemical energy stored by hydrogen fuel

Etsuko Fujita and Gerald Manbeck of Brookhaven Lab's Chemistry Division carried out a series of experiments to understand why their molecular system with six light-absorbing centers (made of ruthenium metal ions bound to organic molecules) produced more hydrogen than the system with three such centers. This understanding is key to designing more efficient molecular complexes for converting solar energy into chemical energy—a conversion that green plants do naturally during photosynthesis.

Finding inspiration from nature

The leaves of green plants contain hundreds of pigment molecules (chlorophyll and others) that absorb light at particular wavelengths. When light of the proper wavelength strikes one of these molecules, the molecule enters an excited state. Energy from this excited state is shuttled along a chain of pigment molecules until it reaches a specific type of chlorophyll in the photosynthetic reaction center. Here, the energy is used to drive the charge-separation process required for photosynthesis to proceed. The electron “hole” left behind in the chlorophyll molecule is used for water-to-oxygen conversion. Hydrogen ions formed during the water-splitting process are eventually used for the reduction of carbon dioxide to glucose in the second stage of photosynthesis, known as the light-independent reaction.

UPTON, NY—Photosynthesis in green plants converts solar energy to stored chemical energy by transforming atmospheric carbon dioxide and water into sugar molecules that fuel plant growth. Scientists have been trying to artificially replicate this energy conversion process, with the objective of producing environmentally friendly and sustainable fuels, such as hydrogen and methanol. But mimicking key functions of the photosynthetic center, where specialized biomolecules carry out photosynthesis, has proven challenging. Artificial photosynthesis requires designing a molecular system that can absorb light, transport and separate electrical charge, and catalyze fuel-producing reactions—all complicated processes that must operate synchronously to achieve high energy-conversion efficiency.

Now, chemists from the U.S. Department of Energy’s (DOE) Brookhaven National Laboratory and Virginia Tech have designed two photocatalysts (materials that accelerate chemical reactions upon absorbing light) that incorporate individual components specialized for light absorption, charge separation, or catalysis into a single “supramolecule.” In both molecular systems, multiple light-harvesting centers made of ruthenium (Ru) metal ions are connected to a single catalytic center made of rhodium (Rh) metal ions through a bridging molecule that promotes electron transfer from the Ru centers to the Rh catalyst, where hydrogen is produced.

Photosystems (PS) I and II are large protein complexes that contain light-absorbing pigment molecules needed for photosynthesis. PS II captures energy from sunlight to extract electrons from water molecules, splitting water into oxygen and hydrogen ions (H+) and producing chemical energy in the form of ATP. PS I uses those electrons and H+ to reduce NADP+ (an electron-carrier molecule) to NADPH. The chemical energy contained in ATP and NADPH is then used in the light-independent reaction of photosynthesis to convert carbon dioxide to sugars.

They compared the hydrogen-production performance and analyzed the physical properties of the supramolecules, as described in a paper published in the June 1 online edition of Journal of the American Chemical Society, to understand why the photocatalyst with six as opposed to three Ru light absorbers produces more hydrogen and remains stable for a longer period of time.

“Developing efficient molecular systems for hydrogen production is difficult because processes are occurring at different rates,” said lead author Gerald Manbeck, a chemist in the artificial photosynthesis group at Brookhaven Lab. “Completing the catalytic turnover of hydrogen before the separated charges—the negatively charged light-excited electron and positive “hole” left behind after the excited molecule absorbs light energy—have a chance to recombine and wastefully produce heat is one of the major challenges.”

Another complication is that two electrons are needed to produce each hydrogen molecule. For catalysis to happen, the system must be able to hold the first electron long enough for the second to show up. “By building supramolecules with multiple light absorbers that may work independently, we are increasing the probability of using each electron productively and improving the molecules’ ability to function under low light conditions,” said Manbeck.

Manbeck began making the supramolecules at Virginia Tech in 2012 with the late Karen Brewer, coauthor and his postdoctoral advisor. He discovered that the four-metal (tetrametallic) system with three Ru light-absorbing centers and one Rh catalytic center yielded only 40 molecules of hydrogen for every catalyst molecule and ceased functioning after about four hours. In comparison, the seven-metal (heptametallic) system with six Ru centers and one Rh center was more than seven times more efficient, cycling 300 times to produce hydrogen for 10 hours. This great disparity in efficiency and stability was puzzling because the supramolecules contain very similar components.

This depiction of the heptametallic system upon exposure to light shows light harvesting by the six Ru centers (red) and electron transfer to the Rh catalyst (black), where hydrogen is produced. Efficient electron transfer to Rh is essential for realizing high catalytic performance.

Manbeck joined Brookhaven in 2013 and has since carried out a series of experiments with coauthor Etsuko Fujita, leader of the artificial photosynthesis group, to understand the fundamental causes for the difference in performance.

“The ability to form the charge-separated state is a partial indicator of whether a supramolecule will be a good photocatalyst, but realizing efficient charge separation requires fine-tuning the energetics of each component,” said Fujita. “To promote catalysis, the Rh catalyst must be low enough in energy to accept the electrons from the Ru light absorbers when the absorbers are exposed to light.”

Through cyclic voltammetry, an electrochemical technique that shows the energy levels within a molecule, the scientists found that the Rh catalyst of the heptametallic system is slightly more electron-poor and thus more receptive to receiving electrons than its counterpart in the tetrametallic system. This result suggested that the charge transfer was favorable in the heptametallic but not the tetrametallic system.

They verified their hypothesis with a time-resolved technique called nanosecond transient absorption spectroscopy, in which a molecule is promoted to an excited state by an intense laser pulse and the decay of the excited state is measured over time. The resulting spectra revealed the presence of a Ru-to-Rh charge transfer in the heptametallic system only.

“The data not only confirmed our hypothesis but also revealed that the excited-state charge separation occurs much more rapidly than we had imagined,” said Manbeck. “In fact, the charge migration happens faster than the time resolution of our instrument, and probably involves short-lived, high-energy excited states.” The researchers plan to seek a collaborator with faster instrumentation who can measure the exact rate of charge separation to help clarify the mechanism.

In a follow-up experiment, the scientists performed the transient absorption measurement under photocatalytic operating conditions, with a reagent used as the ultimate source of electrons to produce hydrogen (a scalable artificial photosynthesis of hydrogen fuel from water would require replacing the reagent with electrons released during water oxidation). The excited state generated by the laser pulse rapidly accepted an electron from the reagent. They discovered that the added electron resides on Rh in the heptametallic system only, further supporting the charge migration to Rh predicted by cyclic voltammetry.

“The high photocatalytic turnover of the heptametallic system and the principles governing charge separation that were uncovered in this work encourage further studies using multiple light-harvesting units linked to single catalytic sites,” said Manbeck.

This research is supported by DOE’s Office of Science.

Brookhaven National Laboratory is supported by the Office of Science of the U.S. Department of Energy. The Office of Science is the single largest supporter of basic research in the physical sciences in the United States, and is working to address some of the most pressing challenges of our time. For more information, please visit science.energy.gov.

Related Links

Scientific paper: "Tetra- and Heptametallic Ru(II),Rh(III) Supramolecular Hydrogen Production Photocatalysts"

ORIGIN: Brookhaven National Lab

June 2, 2017

Contact: Ariana Tantillo, (631) 344-2347, or Peter Genzer, (631) 344-3174

Scientists Hack a Human Cell and Reprogram It Like a Computer

GETTY IMAGES

CELLS ARE BASICALLY tiny computers: They send and receive inputs and output accordingly. If you chug a Frappuccino, your blood sugar spikes, and your pancreatic cells get the message. Output: more insulin.

But cellular computing is more than just a convenient metaphor. In the last couple of decades, biologists have been working to hack the cells’ algorithm in an effort to control their processes. They’ve upended nature’s role as life’s software engineer, incrementally editing a cell’s algorithm—its DNA—over generations. In a paper published today in Nature Biotechnology, researchers programmed human cells to obey 109 different sets of logical instructions. With further development, this could lead to cells capable of responding to specific directions or environmental cues in order to fight disease or manufacture important chemicals.

Large-scale design of robust genetic circuits with multiple inputs and outputs for mammalian cells

Benjamin H Weinberg, N T Hang Pham, Leidy D Caraballo, Thomas Lozanoski, Adrien Engel, Swapnil Bhatia & Wilson W Wong
Affiliations Contributions Corresponding author

Nature Biotechnology 35, 453–462 (2017)

doi:10.1038/nbt.3805
Received 20 June 2016
Accepted 27 January 2017
Published online 27 March 2017

Engineered genetic circuits for mammalian cells often require extensive fine-tuning to perform as intended. We present a robust, general, scalable system, called 'Boolean logic and arithmetic through DNA excision' (BLADE), to engineer genetic circuits with multiple inputs and outputs in mammalian cells with minimal optimization. The reliability of BLADE arises from its reliance on recombinases under the control of a single promoter, which integrates circuit signals on a single transcriptional layer. We used BLADE to build 113 circuits in human embryonic kidney and Jurkat T cells and devised a quantitative, vector-proximity metric to evaluate their performance. Of 113 circuits analyzed, 109 functioned (96.5%) as intended without optimization. The circuits, which are available through Addgene, include a 3-input, two-output full adder; a 6-input, one-output Boolean logic look-up table; circuits with small-molecule-inducible control; and circuits that incorporate CRISPR–Cas9 to regulate endogenous genes. BLADE enables execution of sophisticated cellular computation in mammalian cells, with applications in cell and tissue engineering.

Their cells execute these instructions by using proteins called DNA recombinases, which cut, reshuffle, or fuse segments of DNA. These proteins recognize and target specific positions on a DNA strand—and the researchers figured out how to trigger their activity. Depending on whether the recombinase gets triggered, the cell may or may not produce the protein encoded in the DNA segment.

A cell could be programmed, for example, with a so-called NOT logic gate. This is one of the simplest logic instructions: Do NOT do something whenever you receive the trigger. This study’s authors used this function to create cells that light up on command. Biologist Wilson Wong of Boston University, who led the research, refers to these engineered cells as “genetic circuits.”

Here’s how it worked: Whenever the cell did contain a specific DNA recombinase protein, it would NOT produce a blue fluorescent protein that made it light up. But when the cell did not contain the enzyme, its instruction was DO light up. The cell could also follow much more complicated instructions, like lighting up under longer sets of conditions.

Wong says that you could use these lit up cells to diagnose diseases, by triggering them with proteins associated with a particular disease. If the cells light up after you mix them with a patient’s blood sample, that means the patient has the disease. This would be much cheaper than current methods that require expensive machinery to analyze the blood sample.

Now, don’t get distracted by the shiny lights quite yet. The real point here is that the cells understand and execute directions correctly. “It’s like prototyping electronics,” says biologist Kate Adamala of the University of Minnesota, who wasn’t involved in the research. As every Maker knows, the first step to building complex Arduino circuits is teaching an LED to blink on command.

Pharmaceutical companies are teaching immune cells to be better cancer scouts using similar technology. Cancer cells have biological fingerprints, such as a specific type of protein. Juno Therapeutics, a Seattle-based company, engineers immune cells that can detect these proteins and target cancer cells specifically. If you put logic gates in those immune cells, you could program the immune cells to destroy the cancer cells in a more sophisticated and controlled way.

Programmable cells have other potential applications. Many companies use genetically modified yeast cells to produce useful chemicals. Ginkgo Bioworks, a Boston-based company, uses these yeast cells to produce fragrances, which they have sold to perfume companies. This yeast eats sugar just like brewer’s yeast, but instead of producing alcohol, it burps aromatic molecules. The yeast isn’t perfect yet: Cells tend to mutate as they divide, and after many divisions, they stop working well. Narendra Maheshri, a scientist at Ginkgo, says that you could program the yeast to self-destruct when it stops functioning properly, before they spoil a batch of high-grade cologne.

Wong’s group wasn’t the first to make biological logic gates, but they’re the first to build so many with consistent success. Of the 113 circuits they built, 109 worked. “In my personal experience building genetic circuits, you’d be lucky if they worked 25 percent of the time,” Wong says. Now that they’ve gotten these basic genetic circuits to work, the next step is to make the logic gates work in different types of cells.

But it won’t be easy. Cells are incredibly complicated—and DNA doesn’t have straightforward “on” and “off” switches like an electronic circuit. In Wong’s engineered cells, you “turn off” the production of a certain protein by altering the segment of DNA that encodes its instructions. It doesn’t always work, because nature might have encoded some instructions in duplicate. In other words: It’s hard to debug 3 billion years of evolution.

ORIGINAL: Wired

By SOPHIA CHEN.

03.27.17

Researchers take major step forward in Artificial Intelligence

The long-standing dream of using Artificial Intelligence (AI) to build an artificial brain has taken a significant step forward, as a team led by Professor Newton Howard from the University of Oxford has successfully prototyped a nanoscale, AI-powered, artificial brain in the form factor of a high-bandwidth neural implant.

Professor Newton Howard (pictured above and below) holding parts of the implant device

In collaboration with INTENT LTD, Qualcomm Corporation, Intel Corporation, Georgetown University and the Brain Sciences Foundation, Professor Howard’s Oxford Computational Neuroscience Lab in the Nuffield Department of Surgical Sciences has developed the proprietary algorithms and the optoelectronics required for the device. Rodents’ testing is on target to begin very soon.

This achievement caps over a decade of research by Professor Howard at MIT’s Synthetic Intelligence Lab and the University of Oxford, work that resulted in several issued US patents on the technologies and algorithms that power the device,

• the Fundamental Code Unit of the Brain (FCU),
• the Brain Code (BC) and the Biological Co-Processor (BCP)

are the latest advanced foundations for any eventual merger between biological intelligence and human intelligence. Ni2o (pronounced “Nitoo”) is the entity that Professor Howard licensed to further develop, market and promote these technologies.

The Biological Co-Processor is unique in that it uses advanced nanotechnology, optogenetics and deep machine learning to intelligently map internal events, such as neural spiking activity, to external physiological, linguistic and behavioral expression. The implant contains over a million carbon nanotubes, each of which is 10,000 times smaller than the width of a human hair. Carbon nanotubes provide a natural, high-bandwidth interface as they conduct heat, light and electricity instantaneously updating the neural laces. They adhere to neuronal constructs and even promote neural growth. Qualcomm team leader Rudy Beraha commented, 'Although the prototype unit shown today is tethered to external power, a commercial Brain Co-Processor unit will be wireless and inductively powered, enabling it to be administered with a minimally-invasive procedures.'

The device uses a combination of methods to write to the brain, including

• pulsed electricity,
• light and
• various molecules that simulate or inhibit the activation of specific neuronal groups.

These can be targeted to stimulate a desired response, such as releasing chemicals in patients suffering from a neurological disorder or imbalance. The BCP is designed as a fully integrated system to use the brain’s own internal systems and chemistries to pattern and mimic healthy brain behavior, an approach that stands in stark contrast to the current state of the art, which is to simply apply mild electrocution to problematic regions of the brain.

Therapeutic uses

The Biological Co-Processor promises to provide relief for millions of patients suffering from neurological, psychiatric and psychological disorders as well as degenerative diseases. Initial therapeutic uses will likely be for patients with traumatic brain injuries and neurodegenerative disorders, such as Alzheimer’s, as the BCP will strengthen the weak, shortening connections responsible for lost memories and skills. Once implanted, the device provides a closed-loop, self-learning platform able to both determine and administer the perfect balance of pharmaceutical, electroceutical, genomeceutical and optoceutical therapies.

Dr Richard Wirt, a Senior Fellow at Intel Corporation and Co-Founder of INTENT, the company’s partner of Ni2o bringing BCP to market, commented on the device, saying, 'In the immediate timeframe, this device will have many benefits for researchers, as it could be used to replicate an entire brain image, synchronously mapping internal and external expressions of human response. Over the long term, the potential therapeutic benefits are unlimited.'

The brain controls all organs and systems in the body, so the cure to nearly every disease resides there.- Professor Newton Howard

Rather than simply disrupting neural circuits, the machine learning systems within the BCP are designed to interpret these signals and intelligently read and write to the surrounding neurons. These capabilities could be used to reestablish any degenerative or trauma-induced damage and perhaps write these memories and skills to other, healthier areas of the brain.

One day, these capabilities could also be used in healthy patients to radically augment human ability and proactively improve health. As Professor Howard points out: 'The brain controls all organs and systems in the body, so the cure to nearly every disease resides there.' Speaking more broadly, Professor Howard sees the merging of man with machine as our inevitable destiny, claiming it to be 'the next step on the blueprint that the author of it all built into our natural architecture.'

With the resurgence of neuroscience and AI enhancing machine learning, there has been renewed interest in brain implants. This past March, Elon Musk and Bryan Johnson independently announced that they are focusing and investing in for the brain/computer interface domain.

When asked about these new competitors, Professor Howard said he is happy to see all these new startups and established names getting into the field - he only wonders what took them so long, stating: 'I would like to see us all working together, as we have already established a mathematical foundation and software framework to solve so many of the challenges they will be facing. We could all get there faster if we could work together - after all, the patient is the priority.'

© 2017 Nuffield Department of Surgical Sciences, John Radcliffe Hospital, Headington, Oxford, OX3 9DU

ORIGINAL: NDS Oxford

2 June 2017

The Big, Hot, Expensive Problem Facing Cities Now

Cities will lose billions, and the planet will suffer–but designers could help.

[Photo: Max Ostrozhinskiy/Unsplash]

Certain climate change scenarios lend themselves to the imagination. Our brains can easily understand the risks; they’re almost filmic. Storms intensify. Cities heat up. Drought and disease explode. Coastlines are abandoned. Comparatively, financial losses can seem like an afterthought. But as economists piece together a more complex understanding of how climate change will impact the world, they’re raising the alarm.

The latest warning comes from economists from Mexico, the U.K., and the Netherlands, who show that most estimates of the cost of climate change are missing something important: the fact that global warming will be much worse in cities thanks to the urban heat island effect. Not only will cities be much hotter, they’ll pay for it, losing as much as 11% of their GDP in the most extreme cases. And overall, this “local” warming will make global warming worse. Cities need to act now to increase cool roofs, cool asphalt, and other design changes that can dampen the effect, they argue.

In the 1800s, a British scientist named Luke Howard observed that the temperature in London was consistently higher than nearby areas. Today that phenomenon is called the urban heat island effect: Asphalt, dense architecture, energy usage, and a lack of green space all conspire to make cities much warmer than areas nearby–which actually cascades to dramatically alter the weather patterns around cities in general. The effect also compounds climate change in cities, which see hotter temperatures than what the rest of the world experiences.

[Photo: Vladimir Kudinov/Unsplash]

In the journal Nature Climate Change, the economists Francisco Estrada, W.J. Wouter Botzen, and Richard S.J. Tol write that this “local” form of climate change will deeply depress the urban economy–and dramatically “amplify” global climate change overall. “Any hard-won victories over climate change on a global scale could be wiped out by the effects of uncontrolled urban heat islands,” Tol said in a University of Sussex statement. The impact is so dramatic, the economic losses from climate change are almost three times worse when the urban heat island effect is included in the model, as opposed to conventional models that don’t consider the effect.

The trio ran an analysis of the 1,692 largest cities in the world under several different future greenhouse gas concentration models, ultimately finding that the hardest-hit cities could lose almost 11% of their GDP by 2100 under the most extreme scenario, with average losses at about 5.6%. For a city like New York, which had a GDP of $1.33 trillion in 2012, an 11% loss could mean roughly $146 billion. For comparison’s sake, that’s almost double the city budget Mayor de Blasio proposed this year, or roughly what China spends on defense every year. The urban heat island effect would make any attempts to mitigate climate change on a global scale (say, through international treaties or large-scale efforts) way less effective. In short, if cities don’t start mitigating the urban heat island effect, they’ll be in big trouble economically very soon, and the rest of the world will suffer, too.

While that’s bad news for just about everyone involved, the economists point out a silver lining: Cities are more nimble and flexible to enact policy than hulking national or international governments. They modeled four different levels of policy that cities could make, and found that mitigating the urban heat island effect on a local level could have major benefits on a global scale. “And even when global efforts fail, we show that local policies can still have a positive impact, making them at least a useful insurance for bad climate outcomes on the international stage,” Tol added.

[Photo: Maxvis/iStock]

That includes green roofs and cool roofs, which reflect solar radiation with reflective paint or material, as well as cool pavements, which are made with reflective aggregate to bounce back the sun’s rays. (Expanding green spaces and increasing tree plantings are important, too, they add.)

Some cities are already enacting policy in line with their recommendations: Los Angeles made cool roofs a requirement in 2013, and just last month New York City released guidelines for resilient architecture that include cool roofs and cool pavement, as well as other heat-mitigation designs like bioswales ("...landscape elements designed to concentrate or remove silt and pollution from surface runoff water. They consist of a swaled drainage course with gently sloped sides (less than 6%) and filled with vegetation, compost and/or riprap..."). Meanwhile, many other cities are replacing parking lots with green space and parks. Architects in Phoenix are incorporating heat island-busting canopies into their designs.

Photo: Co.Design

It’s further proof that the battle for the planet will be fought in cities–and that architecture, infrastructure, and urban design will be important weapons against it.

ABOUT THE AUTHOR

Kelsey Campbell-Dollaghan is Co.Design's deputy editor

ORIGINAL: FastCoDesign

BY KELSEY CAMPBELL-DOLLAGHAN

05.31.17

We Could Build an Artificial Brain Right Now

Large-scale brainlike systems are possible with existing technology—if we’re willing to spend the money

Photo: Dan Saelinger

Brain-inspired computing is having a moment. Artificial neural network algorithms like deep learning, which are very loosely based on the way the human brain operates, now allow digital computers to perform such extraordinary feats as translating language, hunting for subtle patterns in huge amounts of data, and beating the best human players at Go.
